A trail bike with its priorities on point: playful agility, progressive design, and killer capability – your favorite trails have never been more fun.
Where it thrives
Challenging trails, up and down hills
What it's built for
Traction, handling, durability
- Carbon frame / Shimano XT/SLX 12-speed drivetrain
- Rockshox Pike Select 140mm fork / Deluxe Select+ shock
- Shimano SLX 4-piston hydro discs / DownLow dropper post
The right stuff
29” wheels with big, grippy tires. Properly wide bars and properly short stems. Powerful brakes and dropper posts. Straightforward parts for straightforward performance.
Easy to love
Designed to be a "daily ride", the Habit is built for easy service with proven, durable suspension pivots, easy internal cable routing and no oddball proprietary stuff.
Utilizing size-specific Center-of-Gravity data, the suspension is custom designed for each frame size so that every rider, from the tallest to the smallest, experiences optimized suspension performance.
The Ai Advantage
Our Ai Offset Drivetrain opens up the rear triangle for more tire clearance, while keeping the chainstays short for nimble agility. A stiffer, stronger rear wheel is just icing on the cake.
A reversable chip allows riders to tweak the geometry - raise the BB and steepen the head angle of by half a degree - or to switch from 29 to 27 Plus wheels.
Have peace of mind, knowing a rugged rubber guard is protecting your piece.
Thru-axle pivot system creates a rock-solid connection between both sides of the swingarm for instantaneous response. No twist, no flex and no special tools required.
|Frame||130mm travel, BallisTec Carbon front triangle, SmartForm C1 Alloy swingarm, Proportional Response Tuned, Ai offset drivetrain, ISCG05, PF30, Post mount brake, tapered headtube|
|Fork||RockShox Pike Select, 140mm, DebonAir, 15 x 110mm thru-axle, tapered steered, 51mm offset|
|Headset||Integrated Sealed Bearing, Tapered|
|Rear Shock||RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound|
|Rims/Wheels||WTB ST i25 TCS, 32h, tubeless ready|
Front: Shimano MT400, 15 x 110mm thru-axle
Rear: Shimano MT510 12 x 148mm thru-axle
|Spokes||DT Swiss Champion|
Front: Maxxis Minion DHF, 29 x 2.5", EXO casing, tubeless ready
Rear: Maxxis Dissector, 29 x 2.4", EXO casing, tubeless ready
|Crankset||HollowGram, BB30a, OPI SpideRing, 32T, Ai offset|
|Bottom Bracket||Cannondale Alloy PressFit30|
|Chain||Shimano SLX, 12-speed|
|Rear Derailleur||Shimano XT|
|Cassette/Rear Cogs||Shimano SLX, 10-51, 12-speed|
|Shifters||Shimano SLX, 12-speed|
|Handlebars||Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm|
|Stem||Cannondale 3, 6061 Alloy, 31.8, 0°|
|Brake Levers||Shimano SLX hydraulic disc|
|Brakes||Shimano SLX hydraulic disc, 4-piston, 180/180mm RT64 rotor|
|Saddle||Fabric Scoop Shallow Sport, steel rails|
|Seat Post||Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M-XL)|
|Accessories & Extras||Custom Cannondale mud guard|
* Subject to change without notice.
|Mantis / X-Large||884603835128||C23301M10XL||CDA2382913L|
